Best Investment Casting Solution
With over 23 years of experience, Trident Steels is one of the leading Investment casting manufacturer -
Specialising in high-quality investment casting
We have a modern plant & have machinery to produce quality investment castings. -
We pride ourselves on being experts
We at Trident Steels offer investment castings for the diverse needs of the engineering industry
Get in touch
ask@tridentcast.in
Location
40, Machhe Industrial Area,
Machhe, Belagavi, 590014
Trident Steels produces investment castings to exacting standards.
About Trident Investment Castings
Investment Casting
Trident is a renowned investment Casting Manufacturer in India. We are well known for our perfect and precision smooth investment casting. Our technology is completely indigenous and in a modified form, depending upon the size, shape, and selected metal. The company deploys the latest machines and their continuous development in quality for producing patterns from complex tooling in various configurations.
Today our focus in employing the lost wax process for intricate designs has become legend. We are the manufacture of protype investment casting in India from rubber molds, machined waxes and epoxy tooling made by a master. Generally, our technical process can pour almost any alloy into the mould for any complex construction of investment Casting Manufacturers.
Our team
Our team offers the most up-to-date, sustainable custom manufacturing solutions.
Our Production
We produce castings in the weight range from a few grammes to about 15 Kgs single piece.
Quality
Quality has always been playing a key role in establishing us as one of the reputed manufacturers of investment castings.
We Manufacture
Trident Steels manufactures
Stainless Steel castings of pipe fittings in S.S304 and S.S316 grades.
Manufacturing Unit
Our modern manufacturing unit enables us to develop the array of castings well within the scheduled time.
Casting Made In
Castings can be made with under-cuts, through or blind holes and tapers.
Numbers Speak for Us
0
Team Members
0
Year of Experience
0
Happy Clients
0
Certification
Certification
We follow a strict Quality Management System and are ISO 9001:2008 certified company. This certification has been certified by Nimbus certification private limited and accredited to ASCB(Europe).
View Certification
Company
Why Us
Experience
You will find investment cast parts in all general engineering applications, more especially in defence, medical, pump, valve, and aviation industries. The basic process of investment castings has been in use for more than 5000 years.
History
The investment castings process has been in exsistence for many hundreds of years. It was only during the second world war, its full potential for mass manufacturing of parts was fully utilized on an industrial scale for casting critical parts like turbine blades.
Support
We are highly professional in all kind of support, we will not compromise on our work efficiency. Do write us your queries, will get back to you shortly.
Request A Quote
INVESTMENT CASTINGS PROCESS VIDEO
Investment Casting Components
Get a Solution for All Industries
Investment casting manufacturer and exporters of a comprehensive range of SS Investment Castings, Metal Investment Castings and Stainless Steel Casting Parts that are widely used in the automobile, bottling, aerospace, gauges,
instrumentation industry etc.
The Investment Casting
Process
Wax Injection Die
A wax injection die or mould is made which is the exact negative replica of the part to be made. This contains pull out cores which form slots, holes etc.
Wax Pattern Injection
Wax is injected into the mould under pressure so as to form a defect free wax pattern which is an exact replica of the part to be made.
Wax Pattern Assembly
The wax pattern is assembled on to a wax sprue. This assembly is known as a tree or a cluster.
1st Coat Slurry Dip
This cluster is dipped into a fine ceramic slurry, drained of excess slurry & held under a cascade of fine ceramic sand. These are high temperature resisting ceramics.
Backup Coat Slurry Dip
The shell is dipped in secondary coat slurry & coated with coarser grits till a layer about 1/4” to 3/8” is formed on the cluster of wax patterns.
Drying Room
In between 2 coats the shell are dried at an appropriate room temperature & humidity.
Flash Fire De-Wax
The shell thus formed is de-waxed to drain out the wax by application of heat.
Pouring Shells 1 or Shells 2
The part is poured in the required metal like alloys of Carbon Steels, Stainless Steels & Copper alloys.
Pneumatic Knockout
After the poured shell have cooled, they are subjected to high impulse hammering to remove the ceramic from the shells.
Dimensional Inspection
The parts are inspected for dimensions & also for other defects, visually.
Packing and Dispatch
Dispatch & shipping - Trident Steels ships its investment cast parts to countries like USA, Spain, United Kingdom Germany etc.
